Infrastructure

Lab Facilities

Fluid Mechanics Lab

Francis Turbine : 1250 rpm / 15hp / 2000lpm discharge
Kaplan Turbine : 2880 rpm / 20hp / 6000lpm discharge
Pelton wheel Turbine : 2880 rpm / 15hp / 3 phase
Flow Measurements : Rotometer, Venturimeter, Orificemeter, Mouthpiece, Notches
Pumps : Centrifugal Submersible, Reciprocating, Gear pumps

Survey Lab

Total Station
Dumpy Level
Micro Optic Theodolites
Hand Held GPS
Plane Table
Levelling Staff
Ranging Rod
Chains, Tapes, Arrows

Strength of Materials Lab

UTM – 40 tonne
Brinnel hardness test
Rockwell hardness
Impact testing machine
Torsion Testing machine
Izod Impact testing machine
Extensometer
Compressometer
Beam deflection test apparatus

Soil Mechanics Lab

Direct shear test
Relative density apparatus
Triaxial testing machine
Consolidation testing machine
CBR testing machine
Proctor Compaction apparatus
Field density testing apparatus
Liquid limit, Plastic limit, Shrinkage limit apparatus
Hydrometer

Concrete Lab

Permeability Testing machine
Compression testing Machine (3000KN)
Los-Angeles Abrasion testing machine
Marshall Stability apparatus
Bituminous Testing Apparatus
Concrete Cube, Cylinder, Prism moulds
Slump cone, Flow table, Vee Bee Consistometer
CBR apparatus

Environmental Engineering Lab

Incubator
Digital turbidity meter
Digital pH meter
Digital Calorie meter
Oxygen Analyzer
Spectrometer
BOD and COD analyzer

Civil Computer Lab

CAD Laboratory has been established over an area of 135 sq.m. and is fully equipped with 62 high-end computers. Software includes AutoCAD 2024 (2D/3D modeling), Staad.Pro V8i (structural analysis), Primavera P6 (project planning), and Revit Architecture 2024 (BIM). All systems are connected via a high-speed internet network.

Structural Engineering Lab

Loading Frame
Hydraulic Jack
Load Cell
Proving Ring
UPV Tester
Rebound Hammer

Plumbing Lab

Pipe vice (2 inch)
Die set (2 inch)
Metallic, Plastic, Flexible pipes
Coupling, Unions, Elbows, and other fittings
